(Domestic 200 WLED Lamps)
1. Vehicle body size: storage time≤1060mm, 830 in wide, 1660mm in height.
2. Elevated height: 4.75m.
★ 3. Lamp appearance: square LED lamps.
4. LED light source: the service life is not less than 30,000 hours, the light source is lit instantly, without flashing, without bulb replacement for life.
★ 5.light number power: LED light source 200W with 4 lights, total light flux 80000 Lm.
6. Lamp switch: can be operated independently, the switch has rain prevention function.
7. Projection angle: the left and right LED lights can manually adjust the angle independently; the lamp assembly can achieve manual horizontal 360° rotation.
8. Irradiation radius: 80 meters.
★ 9. Lifting mode: stainless steel structure, with the function of instant slide self-locking; 4 vertical poles, hand wire rope mechanical lifting.
10. Support fixed: two-way anti-inverted two-point support fixed.
11. Wind resistance requirements: standard configuration of level≥6
12. Chassis structure: reinforced and thickened steel stamping process Vehicle body design structure; hand push steering handle.
★ 13. Tires, hub: 3.50-5 inflatable tires; hub thickness ≥3.0mm, front wheel steering.
★ 14. Power supply mode: standard with EF2600FW gasoline engine power supply.
15, rated voltage: 220V
16. Power generation power: the power is 2KW
17. Working time: 10 hours
18. Backup electrical interface: 220V spare socket.
